Product Description:
The NORGREN pilot explosion-proof solenoid valve operates through electromagnetic force acting on the pilot valve and the pressure difference of the medium to complete the action. When the coil is energized, the pilot valve opens and the working medium in the main valve chamber leaks out through the pilot hole, causing the pressure inside the main valve chamber to decrease and thus opening the main valve using the pressure difference. Conversely, when the coil is powered off, the pilot valve closes, the pressure inside the main valve chamber returns to balance, and the main valve closes as well.
The NORGREN pilot explosion-proof solenoid valve consists of a pilot valve and a main valve that is connected by a pipeline. The main valve can adopt a diaphragm or piston structure. The diaphragm structure is less expensive and less prone to wear, but it requires regular replacement of the rubber diaphragm.
Due to its suitability for high-pressure systems and stable operation in complex media environments, the NORGREN pilot explosion-proof solenoid valves are widely used in industrial settings that require high pressure and complex control, particularly in flammable and explosive environments where they perform exceptionally well.
The solenoid valve is specially designed with an explosion-proof coil to ensure safe operation in flammable and explosive environments, thus providing continuity and safety to the production process.
The piping method of the NORGREN pilot explosion-proof solenoid valve can be installed at any angle. It is recommended that the horizontal pipe wiring ring faces upwards to enhance its service life. Its coil protection level is IP65, making it suitable for various industrial environments.
Technical Parameters:
| Brand | Herion |
| Product Name | NORGREN pilot operated solenoid valve |
| Operation | 5/2 |
| Work Pressure (bar) | 2.5 - 8 |
| Medium | Lubricated Or Non Lubricated Compressed Air That Has Been Filtered |
| Interface Size | 1/4 NPT |
| Materials - Body | Aluminium |
| Description | All aluminum pilot explosion-proof solenoid valve |
Applications:
This indirect solenoid valve is versatile and can be used in various applications such as pneumatic systems, process control systems, and industrial automation. It is ideal for use in situations that require high-speed switching, low power consumption, and high reliability. The Norgren Solenoid Valve is made in China and has a CE certification, ensuring that it meets the required quality standards.
The interface size of this valve is 1/4 NPT which allows for easy installation and a secure connection. It has a work pressure range of 2.5 -8 Bar, which makes it an ideal choice for low-pressure applications. The valve operates on a 5/2 mechanism, which means that it has five ports and two positions. This mechanism allows for efficient operation and quick switching between positions.
The Norgren Solenoid Valve has a minimum order quantity of 1, and the price is negotiable. The delivery time is 1-7 work days after payment, and the payment terms include T/T, Western Union, and Paypal. The supply ability is 5000 pieces/1 Month, ensuring that you can always get the valve when you need it.
This indirect solenoid valve is ideal for various occasions and scenarios, including but not limited to:
- Pneumatic systems
- Process control systems
- Industrial automation
- Food and beverage processing
- Pharmaceutical manufacturing
In conclusion, the Norgren Solenoid Valve is a reliable and efficient product that is ideal for various applications. Its durability, versatility, and ease of installation make it a popular choice for many industries. If you need a high-quality indirect solenoid valve, the Norgren Solenoid Valve is an excellent choice.
Packing and Shipping:
The Norgren Solenoid Valve product will be carefully packaged to ensure it arrives in perfect condition.
Each valve will be placed in a protective foam casing and then placed in a sturdy cardboard box with additional padding to prevent any damage during shipping.
Once packaged, the valve will be shipped via a trusted carrier to ensure timely and secure delivery.
